Parts List
Shop Presses
Service Parts
MODELS: IAP10010, IEP10010, IEPD10010 & IEPDS10010
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
Note: Not all components of the press are replacement items, but are illustrated as a convenient reference of location and
position in the assembly sequence.
Item
Part No. for Model
Description Qty
IAP10010 IEP10010 IEPD10010 IEPDS10010
1 N/A Press Frame w/Winch and Pump Bracket 1
2 N/A Bed Frame 1
3 610-002-003 Support Pin 2
4 IEP-002-004 Frame Base Channel 2
5 IEP-002-005 Lower Cross Member 1
6 400-002-006 Winch 1
7 400-002-007 Cable Sheaves (Pulley) 3
8 610-002-008 Cable 2
9 IEP-002-009 Cylinder Adapter Plate 1
10a H10010 N/A Single Acting Cylinder, 100 ton, 10” Stroke 1
10b N/A HD10010 Double Acting Cylinder, 100 ton, 10” Stroke 1
11a PA7550 N/A Pump, Air, 460.6 in 3 1
11b N/A PEW1002T PEWM1002T PESML1002T Pump, Electric, 1 hp 1
12 N/A PEW01 N/A Pendant Switch 1
13 CS3838C CS3838 Hydraulic Hose 1*
14 CH38M Male Coupler 1*
15 GW4014 Pressure Gauge, 4”, Wet 1
16 CF3814 Gauge Adapter 1
17 AP100 Arbor Plates 1
18 IEP-001-011 Electric Pump Bracket 1
* Qty 2 for IEPD10010 & IEPDS10010 Double Acting Presses
