MODEL: PA3801-HP12
PA3801-HP12
rev 07/2013
Air Hydraulic Pump
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
Note: Not all components of the pump are replacement items, but are illustrated
as a convenient reference of location and position in the assembly sequence.
Parts List
Item
Part No.
Description
Qty
1
A57-6-6001-108 Steel bar
1
2
A57-6-6003-102 Foot pedal
1
3
*
E-clip
2
4
A57-6-2003-102 Foot pedal bar
1
5
D05-6-1001-106 Nut
1
6
A57-6-3007-105 Silencer
1
7
666-5-0160-107 C-clip
1
8
*
O-ring
2
9
*
Back-up ring
2
10
A57-6-4002-201 Oil outlet valve
1
11
512-2-0043-108 Compression spring
1
12
601-7-0009-001 Steel ball
1
13
511-7-0410-102 O-ring
1
14
649-1-0060-040 Screw M6x1x15L
18
15
*
Washer
18
16
A57-6-6008-102 Oil tank cover
1
17
644-1-0060-05311 Screw M6x1x6L
1
18
503-9-0050-106 Steel ball block
1
19
601-7-0006-005 Steel ball
1
20
*
Washer
2
21
A59-6-1017-102 High pressure valve
1
22
A17-6-1216-102 Nail
1
23
512-2-0067-010 Compression spring
1
24
A17-5-1603-300 Screw D10x7L
1
25
601-7-0008-009 Steel ball
1
26
A57-6-6006-108 Oil entrance valve
1
27
520-8-0134-101 Filter
1
28
A57-6-6009-104 Pad
1
29
H23-6-1000-102 Magnet
1
30
A57-6-6007-201 Reservoir
1
31
649-1-0060-122 Screw M6x1x120L
4
32
A57-6-1002-105 Motor cover
1
33
A17-6-2105-108 Cylinder washer
2
34
A17-4-2100-500 Air piston assy.
1
35
A57-6-1003-107 Cylinder
1
36
A59-3-1013-106 Piston assy.
1
37
512-2-0410-017 Compression spring
1
38
A57-6-1014-102 Piston cover
1
39
A59-5-2023-106 Bush
1
Item
Part No.
Description
Qty
40
*
Back-up ring
1
41
*
U-cup
1
42
A58-6-1013-107 Pump
1
43
A57-6-1016-106 Washer
1
44
H18-6-8103-104 Special washer
1
45
A57-6-1001-204 Base
1
46
A57-6-1605-105 Pad B
1
47
511-7-0140-200 O-ring
2
48
512-2-0092-101 Compression spring
1
49
649-1-0040-007 Screw M4x.7x6L
1
50
A57-6-5004-109 Air entrance cap
1
51
511-7-0053-104 O-ring
1
52
A17-6-1105-103 Plastic cap
1
53
A57-6-2062-108 Connector
1
54
A57-6-5001-103 Air entrance base
1
55
A57-6-5003-107 Air entrance valve
1
56
511-7-0080-309 O-ring
1
57
649-1-0050-046 Screw M5x0.8x30L
6
58
A57-3-1900-109 Vent Plug assy
1
59
512-2-0061-100 Compression spring
1
60
644-1-0040-204 Screw M4x0.7x4.1L
1
61
*
Compression spring
1
62
503-9-0035-100 Steel ball block
1
63
601-7-0003-009 Steel ball
1
64
A57-6-3003-305 Release valve
1
65
A57-6-3004-307 Release base
1
66
*
O-ring
1
67
*
Back-ring
1
68
552-2-0010-105 Compression spring
1
69
*
Release nail
1
70
A57-6-3001-112 Release bar
1
71
*
O-ring
1
72
*
Pad A
1
73
666-5-0250-108 C-clip
1
74
A17-6-1002-103 Silencer
1
75
A57-6-6005-106 Dust cap
1
76
A57-6-6004-104 Oil outlet base
1
77
A57-6-5101-107 Leaf spring
1
78
549-1-0050-055 Screw M5x0.8x16L
2
(*)
A18-3-9900-104 Seal kit
-
(*) indicated items included in, and available only as part of Seal Kit
