BEFORE USE AND SET UP
1. Familiarize yourself with the specifications and
illustrations in this owners manual. Know your pump,
its limitations and how it operates before attempting to
use. Refer to specification chart on page 2 for details
of oil port thread size, usable oil capacity, and more.
If in doubt, contact BVA Hydraulics Technical Service
(888) 332-6419.
2.
Replace shipping plug (red color) with air vent plug
(black color) before use.
3.
Air Connection: Remove plastic cap, connect suitable
air supply to air input port. Air input port is designed to fit
the popular 1/4" NPT air nipple (not included). Ensure
that your air source can dedicate 7.8CFM @ 110~175 PSI
to each pump operated.
4.
Hydraulic Connection: Clean all areas around the oil
port of pump and cylinder. Inspect all threads and fitting
for signs of wear or damage and replace as needed.
Clean all hose ends, couplers and union ends. Remove
the manifold plug, then connect oil output port to suitable
fittings and application/cylinder.
NOTICE: Always secure threaded port connections with
high grade, non-hardening pipe thread sealant. Teflon
tape can be used if only one layer of tape is used and it
is applied carefully, two threads back, to prevent the tape
from being introduced into hydraulic system, which could
cause jamming of precision-fit parts.
WARNING: To reduce the risk of personal injury and/or
property damage, Hydraulic connections must be securely
fastened before building pressure in the system. Release all
system pressure before loosening any hydraulic connection
in the system.
OPERATION
WARNING: Always monitor pressure, load or position
using suitable equipment. Pressure may be monitored by
means of an optional manifold and gauge. Load may be
monitored by means of a load cell and digital indicator.
Correct application position can only be determined by the
operator of the equipment.
1. To extend the cylinder, depress on the foot pedal marked
"Pump" (horizontal portion) until desired pressure, load
or position is reached.
2. To hold the cylinder in position, release the foot pedal to
deactivate the pump.
3. To retract the cylinder, depress the release valve by
stepping on the foot pedal marked "Release" (raised,
stirrup shaped portion).
4
WARNING: Never operate a pump which is
disconnected from application. If operated in this
condition, the hose and connections will become
pressurized. This increases burst hazard. Damage may
occur to pump and its components.
MAINTENANCE
Important: Use only good quality hydraulic fluid. Never use
brake fluid, transmission fluid, turbine oil, motor oil, alcohol,
glycerin etc. Use of other than good quality hydraulic
oil will void warranty and damage the pump, hose, and
application. We recommend premium hydraulic fluid or F01
BVA Hydraulic fluid.
1. Inspect hoses and connections daily. Replace damaged
components immediately.
2. Tighten connections as needed. Use non-hardening pipe
thread compound when servicing connections.
Adding Hydraulic Fluid
1. Depressurize and disconnect hydraulic hose from
application/ cylinder.
2. With pump in its upright, horizontal position, remove the
air vent plug located on the top plate of the reservoir.
3. Use a small funnel to fill the oil to within 3/4" (19mm)
of the opening.
4. Wipe up any spilled fluid and reinstall the air vent plug/
reservoir cap.
Changing Hydraulic Fluid
1. For best results, change fluid once a year or every 300
hours of use.
2. Repeat # 2 above, then pour used fluid into a sealable
container.
3. Dispose of fluid in accordance with local regulations.
4. Fill with a good quality hydraulic fluid as recommended
above. Reinstall air vent plug/ reservoir cap.
Lubrication
When pump is operated on daily basis, the manufacturer
recommends installing an inline oiler and air dryer. Use SAE
grade oil (5W to 30W).
Storage
1. When not in use, depressurize and disconnect hydraulic
pump from application.
2. Wipe clean, thoroughly and store in clean, dry
environment. Avoid temperature extremes.
3. For transportation or long storage, replace the air vent
plug with shipping plug.
!
!
!
