(*) - indicates items included in, and available only as part of Repair Kit

N/A - not a component of in this model, or is not available as replacement

Item

Part Number for Model:

Description

Qty

HC1203XT

HC2002T

HC2006T

HC3002T

HC3006T

1

H32-6-2305-100

H32-6-2306-102

H32-6-2307-104

Protecting Cap

1

2

*

O-ring

1

3

H32-6-1821-103

H32-6-1822-105

H32-6-1823-107

Upper Bearing

1

4

512-2-0490-103 512-2-0710-101 512-2-0740-100 512-2-0815-105 512-2-0835-101 Return Spring

1

5

*

Back-up Ring

1

6

*

U-cup

1

7

N/A

Ram Plunger

1

8

*

O-ring

1

9

*

Back-up Ring

1

10

*

U-cup

1

11

N/A

Cylinder Housing

1

12

*

O-ring

1

13

*

Back-up Ring

1

14

N/A

Center Tube

1

15

666-5-0300-107

666-5-0500-105

666-5-0550-100

C-clip

1

16

H02-4-6001-104

Female Coupler

1

17

H02-4-6003-108

H02-4-6003-108

H02-4-6003-108

Dust Cover

1

18

H02-6-1008-105

H02-6-1008-105

H02-6-1008-105

Rubber Plug

1

19

H32-6-1122-107

H32-6-1126-105

H32-6-1131-108 H32-6-1130-106 Bearing

1

20

H32-6-1121-105

H32-6-1125-103

H32-6-1129-101

Bearing

1

21

N/A

H32-6-1103-204

H32-6-1104-206

Saddle

1

(*)

H32-3-9905-101

H32-3-9902-105

H32-3-9901-103

Repair Kit

-

Parts List

Note: Not all components of the cylinder are replacement items, but are illustrated as a convenient reference of location

and position in the assembly sequence.

MODELS: HC1203XT, HC2002T, HC2006T, HC3002T & HC3006T

(ref parts illus pg 8)

Single Acting,

Hollow Hole Cylinders

Service Parts
