2

SAFETY and GENERAL INFORMATION

Save these instructions. For your safety, read and understand the information contained within. The owner and operator shall

have an understanding of this product and safe operating procedures before attempting to use this product. Instructions and

safety information shall be conveyed in the operator’s native language before use of this product is authorized. Make certain that

the operator thoroughly understands the inherent dangers associated with the use and misuse of the product. If any doubt exists

as to the safe and proper use of this product as outlined in this factory authorized manual, remove from service immediately.

Inspect before each use. Do not use if leaking, broken, bent, cracked or otherwise damaged parts are noted. If the cylinder has

been or suspected to have been subjected to a shock load (a load dropped suddenly, unexpectedly upon it), discontinue use

until checked out by a BVA Hydraulics authorized service center. Owners and operators of this equipment shall be aware that

the use and subsequent repair of this equipment may require special training and knowledge. It is recommended that an annual

inspection be done by qualified personnel and that any missing or damaged parts, decals, warning/safety labels or signs be

replaced with BVA Hydraulics authorized replacement parts only. Any cylinder that appears to be damaged in any way, is worn

or operates abnormally shall be removed from service immediately until such time as repairs can be made.

PRODUCT DESCRIPTION

BVA Hydraulics Single Acting Hollow Hole Cylinder is designed for rated capacity pushing, spreading and pressing jobs. A wide

variety of applications exist for this category of product. Special skill, knowledge and training may be required for a specific task

and the product may not be suitable for all the jobs described above. Unsuitable applications would include applications that

call for a device to move, level or support persons, animals, hazardous materials, mobile homes/dwellings in general, mirrors

and/or plate glass, and/or to connect/secure hatches, components, etc. between bulkheads. The user ultimately must make the

decision regarding suitability of the product for any given task and therefore accept responsibility for that decision.

Immediately

after lifting, loads must be supported by appropriate mechanical means.

WARNING: NEVER use hydraulic cylinder as a support device!
WARNING: Always check connections before using. Alteration of these products is strictly prohibited. Use only those

adapters and attachments provided and approved by the manufacturer.
WARNING: To reduce the risk of personal injury and/or property damage, ensure that the rated working pressure of each

pressurized attachment be equal to or greater than the rated working pressure developed by the hydraulic pump.

SPECIFICATIONS

Model

Number

Cylinder

Capacity

(ton)

Stroke

(in)

Cylinder

Effective

Area

(in

2

)

Internal

Pressure at

Capacity

(psi)

Oil

Capacity

(in

3

)

Collapsed

Height

(in)

Extended

Height

(in)

Ram

Plunger

I.D.

(in)

Ram

Plunger

O.D.

(in)

Ram

Plunger

Internal

Thread

Collar

Thread

(in)

HC1201T

12

0.31

2.91

8,240

0.89

2.36

2.67

0.77

1.38

3/4”-

16UN

2 3/4”-16

HC1202T

1.61

4.70

4.75

6.36

HC1202XT

N/A

HC1203XT

2.99

8.72

7.25

10.24

HC2002T

20

2.01

4.90

8,163

9.83

6.38

8.39

1.06

2.15

1 9/16”-

16UN

3 7/8”-12

HC2006T

6.06

29.70

12.05

18.11

HC3002T

30

2.52

6.33

9,479

15.93

7.05

9.57

1.31

2.48

1 13/16”-

16 UN 4 1/2”-12

HC3006T

6.11

38.67

13.02

19.13

HC6003T

60

3.00

13.05

9,195

39.10

9.77

12.77

2.13

3.66

2 3/4”-16

UN

6 1/4”-12

HC6006T

6.00

78.25

12.76

18.76

HC10003T

100

3.00

22.14

9,033

66.31

10.00

13.00

3.11

4.92

4”-16UN 8 3/8”-11

!

!

!
