Page 7
7
Item
Part Number
Description
Qty.
1
631-1-0120-102
Eyebolt
2
2
*
Wiper Seal
1
3
H62-6-1101-103
Saddle
1
4
649-1-0120-207
Bolt
1
5
N/A
Ram
1
6
N/A
Cylinder
1
7
*
T-seal Assembly
1
8
*
O-ring
1
9
*
Back-up Ring
1
10
H62-6-1601-103
Cylinder Base
1
11
H02-4-6001-104
Female Coupler
1
12
H02-4-6003-108
Dust Cap Assembly
1
13
H18-6-8104-106
Hex Socket Pipe Plug
1
14
641-1-0167-106
Hex Socket Pipe Plug
1
(*)
H62-3-9901-107
Seal Kit
-
High Tonnage
Single Acting Cylinders
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
MODELS:
HG15002, HG15004, HG15006, HG15008, HG15010, HG15012, HG20002,
HG20006, HG20008 & HG20012
Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and
position in the assembly sequence.
Note: To ensure safe and reliable performance, replace worn or damaged parts with BVA Hydraulics Authorized
Replacement Parts only.
(*) - indicates items included in, and available only as part of Seal Kit
N/A - part is not available as replacement
