7
CURRENT CONTROL
7) Current Coarse Control. Coarse adjustment of current limit. Read value on the
red LED display.
8) Current Fine Control. Fine adjustment of current limit. Read value on the red LED
display.
POWER CONTROLS
9) Power ON-OFF Switch.
10) Output ON-OFF Switch.
OUTPUT TERMINALS
11) “-” Terminal (Black). Negative polarity output terminal.
12) GND Terminal. Earth and chassis ground.
13) “+” Terminal (Red). Positive polarity output terminal.
3.2 Rear Panel
Figure 2 - Rear Panel
14) Power Cord
15) Fuse
16) RS-232 Interface Connector
16
15
14
