Step 2: Connecting The AirLink GL6110 GSM Modem w/USB To Your PC
1. Go to the ‘Downloads’ section on the AVTECH website (AVTECH.com/Downloads). Login using the Username
and Password emailed to you when you purchased your Room Alert or TemPageR monitor. Click to download
the GSM Plugin (purchased separately) onto the host PC that is running AVTECH’s Device ManageR application
software. Follow the download instructions as prompted.
2. Connect the USB end of the Micro-fit cable into the USB port on the PC running Device ManageR.
Step 1: Setting Up The AirLink GL6110 GSM Modem w/USB
1. Open the SIM card holder and insert your SIM card into the SIM card socket on the
front of the AirLink GL6110 GSM Modem. The SIM card should slide easily into the
holder (see figure A). Push the SIM card all the way in until you hear a clicking sound.
Once the SIM card is in place, close the SIM card holder. (To extract the SIM card,
simply push the SIM card until you hear a clicking sound. The SIM card should spring
out of the socket and can then safely be removed from the holder).
2. Connect the included FME Antenna to the RF connector on the back of the AirLink
GL6110 GSM Modem (see figure B). Make sure that the antenna is securely fastened.
3. Connect the Micro-fit USB cable into the 8-Pin Micro-Fit connector on the back of the
modem (see figure C). This cable provides the USB connection and is used as the power
source for the GL6110.
CAUTION: Make sure that you are using the cable that was supplied with your AirLink GL6110 modem. Using a different
8-Pin Micro-fit cable or interchanging cables between modems may damage either the modem or the PC.
Application Note
Device ManageR
A - SIM
B - Antenna
C - USB
Sierra Wireless AirLink GL6110
Instructions For Connecting The AirLink GL6110 GSM Modem w/USB
To Your PC And Configuring It For Use With Device ManageR
111128.02
The AirLink GL6110 GSM Modem w/USB Connect offers immediate connectivity of AVTECH’s Room Alert and
TemPageR monitors to any GSM / GPRS network. Follow the instructions below for easy and immediate installation and
configuration of the AirLink GL6110 modem on your PC, for use with AVTECH’s Device ManageR application software.
