34 www.anestiwata.com
Ref # Part # Description Remarks
1 93662610 AIR CAP SET “W101-H4” W101A/100A
2 93746610 NOZZLE/NEEDLE SET 1.0 W101A/100A
2 93666610 NOZZLE/NEEDLE SET 1.3 W101A/100A
2-1 93747610 FLUID NOZZLE 1.0 W101A/100A, MARKED W101/T10
2-1 93667610 FLUID NOZZLE 1.3 W101A/100A, MARKED W101/13
2-2 93537600 FLUID NEEDLE 1.0 MARKED AS 10008H
2-2 93578530 FLUID NEEDLE 1.3 MARKED AS 10013
5 N/A GUN BODY
5-1 93660300 AIR NIPPLE 1/4”
5-2 93584530 FLUID NIPPLE 1/4”
6 93842531 PATTERN ADJUST SET
7 93843530 AIR VALVE SEAT SET
7-1 96638008 O RING
8 93591530 AIR VALVE
9 93719530 AIR VALVE SPRING
11 93593530 FLUID NEEDLE SPRING
13 93595530 AIR VALVE SHAFT
14 93845531 AIR ADJUST SET
15 93667360 TRIGGER STUD
16 93597530 TRIGGER
17 93912030 STOPPER 2PCS/PACK
20 93500510 AIR TUBE FOR GRAVITY FEED
20 93507510 AIR TUBE FOR SIPHON FEED
21 93858610 AIR MOTOR/LID SET FOR GRAVITY FEED
21 93856610 AIR MOTOR/LID SET FOR SIPHON FEED
22 94000092 CONTAINER ONLY (PC4S) FOR GRAVITY FEED
22 94000050 CONTAINER ONLY (PC2) FOR SIPHON FEED
23 93857610 QUICK FLUID ADJUST SET
23-1 FLUID ADJUST LEVER SUPPLIED AS SET
23-2 FLUID ADJUST KNOB SUPPLIED AS SET
23-3 FLUID ADJUST SCREW SUPPLIED AS SET
23-4 LOCKING NUT SUPPLIED AS SET
23-5 DIAL PLATE SUPPLIED AS SET
23-6 93861610 FLUID ADJUST GUIDE SET
25 93765610 CARTRIDGE PACKING
501 96801161 HALF UNION FOR GRAVITY FEED
502 96800161 ELBOW UNION FOR SIPHON FEED
503 97992436 FLOW CONTROL VALVE
504 93503510 ADAPTOR
93576530 L GASKET (BLACK) FOR AIR CAP SET
93608320 AIR CAP GASKET (WHITE)
93538600 GUN WRENCH
5650 REPAIR SERVICE KIT 7-1, 9, 11, 15, 17, 25
2950 MK5 MAINTENANCE KIT
Manual Spray Guns
W101A
Agitator Gun
