Ref # Part # Description Remarks
1 93704610 AIR CAP SET “W101-E2P" W101/100
2 93706610 NOZZLE/NEEDLE SET 0.8 W101/100
2 93691610 NOZZLE/NEEDLE SET 1.0 W101/100
2 93666610 NOZZLE/NEEDLE SET 1.3 W101/100
2 93698610 NOZZLE/NEEDLE SET 1.5 W101/100
2-1 FLUID NOZZLE SUPPLIED AS SET
2-2 FLUID NEEDLE SUPPLIED AS SET
5 N/A GUN BODY
5-1 93660300 AIR NIPPLE 1/4”
5-2 93515600 FLUID NIPPLE 3/8”
5-2 93584530 FLUID NIPPLE 1/4” (OPTION)
6 93842531 PATTERN ADJUST SET
7 93843530 AIR VALVE SEAT SET
7-1 96638008 O RING
8 93591530 AIR VALVE
9 93719530 AIR VALVE SPRING
10 93844531 FLUID ADJUST GUIDE SET
11 93593530 FLUID NEEDLE SPRING
12 93594532 FLUID ADJUST KNOB
13 93595530 AIR VALVE SHAFT
14 93845531 AIR ADJUST SET
15 93667360 TRIGGER STUD
16 93597530 TRIGGER
17 93912030 STOPPER 2PCS/PACK
20 93765610 CARTRIDGE PACKING
93576530 L GASKET (BLACK) FOR AIR CAP SET
93608320 AIR CAP GASKET (WHITE)
93538600 GUN WRENCH
5650 REPAIR SERVICE KIT 7-1, 9, 11, 15, 17, 20
2950 MK5 MAINTENANCE KIT
Manual Spray Guns
W101
Pressure Feed
