Manual Spray Guns
LPH101LVG/LVS
Gravity and Siphon
Feed
Ref # Part # Description Remarks
1 93875602 AIR CAP SET “LPH101-LV4”
2 93867600 NOZZLE/NEEDLE SET 1.2LV LPH100LVG
2 93862600 NOZZLE/NEEDLE SET 1.4LV LPH100LVG/LVS
2 93869600 NOZZLE/NEEDLE SET 1.6LV LPH100LVG/LVS
2 93871600 NOZZLE/NEEDLE SET 1.8LV LPH100LVG
2-1 93544600 FLUID NOZZLE 1.2LV MARKED AS 100LV/12
2-1 93542600 FLUID NOZZLE 1.4LV MARKED AS 100LV/14
2-1 93545600 FLUID NOZZLE 1.6LV MARKED AS 100LV/16
2-1 93546600 FLUID NOZZLE 1.8LV MARKED AS 100LV/18
2-2 93537600 FLUID NEEDLE 1.2 MARKED AS 10008H
2-2 93578530 FLUID NEEDLE 1.4/1.5/1.6 MARKED AS 10013
2-2 93703530 FLUID NEEDLE 1.8 MARKED AS 10018
5 N/A GUN BODY
5-1 93660300 AIR NIPPLE 1/4”
5-2 93584530 FLUID NIPPLE 1/4”
6 93842531 PATTERN ADJUST SET
7 93843530 AIR VALVE SEAT SET
7-1 96638008 O RING
8 93591530 AIR VALVE
9 93719530 AIR VALVE SPRING
10 93844531 FLUID ADJUST GUIDE SET
11 93593530 FLUID NEEDLE SPRING
12 93594532 FLUID ADJUST KNOB
13 93595530 AIR VALVE SHAFT
14 93845531 AIR ADJUST SET
15 93667360 TRIGGER STUD
16 93597530 TRIGGER
17 93912030 STOPPER 2PCS/PACK
20 93765610 CARTRIDGE PACKING
93576530 L GASKET (BLACK) FOR AIR CAP SET
93608320 AIR CAP GASKET (WHITE)
93538600 GUN WRENCH
5650 REPAIR SERVICE KIT 7-1, 9, 11, 15, 17, 20
2950 MK5 MAINTENANCE KIT
2985B TEST CAP GAUGE SET “LPH101-LV4”
