2. Installation
31
031-165-C0-001 Rev. A
2.6.4.
Battery Connection
2.6
Battery Installation,
continued
Tools Needed:
Two 7/16” open end wrenches
DC Voltmeter
Procedure:
For UPE-4:
1.
Slide the battery tray out to the stops.
2.
Install four batteries, position batteries as shown in Fig. 2-6.
3.
Wire in accordance with Fig. 2-6.
DANGER:
Battery drawer slides may be damaged if drawer is forced into enclosure
while slide latch is engaged.
4.
Unlatch and slide the tray evenly into the enclosure.
5.
Using a DC Meter, measure the voltage at the power supply connector,
verify that the voltage is between 36 and 40.5 VDC for UPE3 or 48 and 54
VDC for UPE-4.
6.
DO NOT connect the battery pack to the power supply at this time.
For UPE-8:
1.
Slide the upper battery tray out to the stops.
2.
Install four batteries, position batteries as shown in Fig 2-7
3.
Wire in accordance with Fig. 2-7.
DANGER:
Battery drawer slides may be damaged if drawer is forced into enclosure
while slide latch is engaged.
4.
Unlatch and slide the upper battery tray evenly into the enclosure.
5.
Slide the lower battery tray out to the stops.
6.
Install three or four batteries, position batteries as shown in Fig 2-6 or
Fig 2-7.
7.
Wire in accordance with Fig. 2-6 or Fig. 2-7.
8.
Unlatch and slide the lower battery tray evenly into the enclosure.
9.
Using a DC Meter, measure the voltage at the power supply connector,
verify that the voltage is between 36 and 40.5 VDC for UPE6 or 48 and 54
VDC for UPE-8.
10.
DO NOT connect the battery pack to the power supply at this time.
