Continued, Installation, 3 enclosure installation – Alpha Technologies UPE-6L User Manual
Page 20
2. Installation
20
031-178-C0-001 Rev. A
2.3 Enclosure Installation,
continued
2.3.2 Attaching the External Coax Raceway
The external coax raceway is held in place by two tabs at the bottom of the raceway
that fit into slots at the bottom of the enclosure, and a wingnut at the top.
Wing-Nut
Rear wall of UPE
External Coax
Raceway
Retaining Tab
SPI
SPI
Fig. 2-2 External Coax Raceway
