Detailed specifications for each supported enclosure are in the security bar field installation manual (search for Alpha part
number 745-847-C1-001) available at www.Alpha.com. The FPE enclosure is shown below as an example.
Figure 4, Side Bracket Installation
(Left bracket installation is mirrored)
(FPE Enclosure shown as an example))
CARRIAGE BOLT
1/4"-20 X 3/4"
FLAT WASHER 1/4" (2 PLACES)
LOCK WASHER 1/4" (2 PLACES)
NUT 1/4"-20 (2 PLACES)
ENCLOSURE DOOR
LOCK BRACKET
Figure 5, Lock Bracket Alignment and Installation
LOCK BAR
LOCK
LOCK GUARD
Figure 6, Lock Guard Installation
Figure 3, Drill Locations
Figure 2, Marking Bracket Locations
The security bar and lock bracket lock holes must line up before securing the lock
bracket to the enclosure door, see Figure 5.
NOTE:
Step1
Step 2
Step 3
Step 4
