041-028-B1-001 Rev. B (09/2012) 3
Total Power Solutions
5.0 Changing Engine Oil
1. Open and remove the oil maintenance cover (see Figure 5-1).
2. Place a suitable container below the engine to catch the used oil, then remove the oil filler cap/dipstick. Using
a 10mm wrench remove the drain plug and sealing washer (see Figure 5-1).
3. Allow the used oil to drain completely, then reinstall the drain plug and sealing washer. Tighten the plug
securely.
Note: Improper disposal of engine oil can be harmful to the environment and may violate local and federal
laws. Dispose of the used oil in accordance with all local, state and federal laws.
4. With the generator in a level position, fill to the outer edge of the oil filter hole with the recommended oil (see
Figure 5-2).
5. Screw in the oil filler cap/dipstick securely.
6. Reinstall, close, and latch the oil maintenance cover.
Note: Always wash your hands after handling motor oil.
Figure 5-1, Draining oil.
Oil Filler Cap
Upper Limit
Oil Drain Plug
Oil Maintenance
Cover
Dipstick
AMBIENT TEMPERATURE
Drain Screw
Figure 5-2, Filling oil limit.
Oil Filler Cap
Upper Limit
Oil Drain Plug
Oil Maintenance
Cover
Dipstick
AMBIENT TEMPERATURE
Drain Screw
4.0 Engine Oil Recommendations
Oil affects performance and service life for the engine. Always use 4-stroke automotive detergent oil. The engine
can hold .58 U.S. qt (.55 L) of oil.
SAE 10W-30 is recommended for general use. Other viscosities shown in the chart may be used when the average
temperature in your area is with the recommended range (see Figure 4-1).
Figure 4-1, Oil recommendations for ambient temperature.
Oil Filler Cap
Upper Limit
Oil Drain Plug
Oil Maintenance
Cover
Dipstick
AMBIENT TEMPERATURE
Drain Screw
The SAE oil viscosity and service category are in the API label on the oil container. We recommend that you use
API SERVICE category SJ or later (or equivalent) oil.
CAUTION!
Hot engine oil can BURN. The engine should be warm to the touch but not hot when changing the oil.
Draining warm oil assists rapid and complete draining.
