CUSTOMER
ALARM
CONNECTIONS
P1 - 24 VDC
P2 - 24 VDC
NORMALLY
OPEN
1
P4
ALARM
OUT (-)
P3
P2 P1
NORMALLY
OPEN
P1 - 48 VDC
P2 - 48 VDC
1
P4
ALARM
OUT (-) P3
NORMALLY
OPEN
LIST 2 -48 VDC
NOTE: CUSTOMER CAN CHANGE
P3 SETTINGS IF DESIRED
SIZE DWG NO. TYPE
B
SHEET
TITLE
ISSUE
DATE OF
SCALE
REV 020-675-08
CUSTOMER CONNECTION
19" BULLET BREAKER PNL.
3 3
D2
c 2005 ARGUS TECHNOLOGIES O
B
DIMENSIONS ARE IN INCHES WITH METRIC (mm) IN BRACKETS: INCHES [mm]
1 : 4
FOR MANUFACTURING WITHOUT ITS WRITTEN CONSENT.
THESE DESIGNS AND SPECIFICATIONS ARE THE PROPERTY OF
ARGUS TECHNOLOGIES AND SHALL NOT BE COPIED OR USED
LIST 50,81 : DUAL FEED
A
LIST 50,80 : SINGLE FEED
DETAIL A
TYPICAL ALARM WIRING
SCALE 1 : 2
PIN 3 - ALARM OUT (-)
PIN 4 - ALARM COMMON
PIN 1 & 2
ALARM CONTACTS
FACTORY ALARM BOARD
JUMPER SETTINGS
P1 P2
P3
ALARM
OUT (-)
P4
1
LIST 1 +24 VDC
B
LIST 14 +12 VDC
