Table 1-1, fbe specifi cations – Alpha Technologies Fiber Backhaul Enclosure (FBE) User Manual
Page 10

10
021-081-B0-001 Rev. A
1.0 Introduction
1.2
Fiber Backhaul Enclosure (FBE) Specifi cations
Table 1-1, FBE Specifi cations
Fiber Backhaul Enclosure
Material:
Aluminum
Exterior Finish:
Powdercoated exterior
Exterior hardware:
Stainless Steel
Interior hardware:
Stainless Steel and/or Zinc plated
Mechanical
Dimensions (maximum)
Fiber Backhaul Enclosure
Fiber Backhaul Enclosure
(
with Battery Cabinet)
Width (in/mm):
23/584
23/584
Height (in/mm):
27/686
41/1041
Depth (in/mm):
22.3/565
22.3/565
Weight (lbs/kg):
57/26
82/37.5
Enclosure External Mounting:
Wall or H-bracket
Enclosure Internal Mounting:
Adjustable (front to back) 19” equipment rack.
11RU with maximum equipment depth of 15", up to 17" without optional din rail and ground bar
Door(s):
Front: Hinged, with quarter-turn Telecom-grade locks
Demark/craft access - 2RU in height for eight RJ45 connectors with surge protection and two
LGX fi ber connector panels
Knockouts:
2 x 2", 2 x 1.5", 4 x 0.75"
Environmental
Cooling:
Redundant fans; 24 or 48Vdc, ball bearing, sealed, >70,000hr MTBF
Solar Insulation:
3/16" foil blanket (minimum)
Vent/Bug Screen:
20x20 mesh
Operating Temperature:
-40° to 120°F/-40° to 49°C
Safety
Agency Standards:
CSA
CSA C22.2 No 60950-01-07; 60950-22-07
UL
UL 60950-1; UL 60950-22-2007
Cabinet
NEMA Type 3R
Optional Service Entrance:
SUSE rated
Grounding:
Permanent chassis ground for #6AWG wire
* "Information Technology Equipment Safety"
