5. Installation
Attention: Please comply with the following instructions if you are using CAT5 UTP cable.
DIP switch function: The DIP switches at the back side of transmitter/receiver can be used to adapt the sync signal to the UTP cable
length. This setting can be disregarded on using STP cable.
The DIP-switch setting can be done in stages from 1 -15. The DIP switch numbers are added, the outcome of this is current stage
(e.g. 2 + 3 = stage 5).
1. Please set the DIP switch to stage 5 for transmitter and receiver at first (DIP switch 2 and 3 activated). Then connect all the
cables and check the monitor picture.
2. If interferences occur, please increase the DIP switch stage (e.g. 1 + 2 + 3 = stage 6). Connect the cables again and check the
monitor picture.
3. If still interferences occur please repeat step number 2.
