English
5. Place the dome back in the housing and close the housing.
6. Drill four holes in the wall to match the mount, and push the straddling dowels into the wall.
7. Attach the seal between the wall and mount using the straddling dowels to help you.
8. Install the mount using the washer and the nut.
9. Attach the Teflon strip to the thread of the adapter and then screw this into the mount.
The straddling dowels must be used for stone walls. Wood screws (self-tapping) can be used for
wooden walls.
Make sure that the wall is strong enough to bear more than 8 times the weight of the Speed
Dome and its mount.
Straddling dowel
Washer and nut
