43
ZONES
ZONE NUM
1
UNDEFINED -
EDIT LABEL -
EDIT ZONE -
ZONE STATUS ON
SCAN STATUS ON
DELE ZONE -
Function Description
ZONE NUM There are up to eight freely configurable zones
UNDEFINED Name of the zone (UNDEFINED appears if no name is
specified)
EDIT LABEL Editing of name
EDIT ZONE Setting of the zone
ZONE STATUS Display of the zone status
SCAN STATUS Switching on and off of the scans in the zone
DELE ZONE Deletion of the current zone; the zone status then changes
to OFF
LINE SYN
LINE LOCK
OFF
V-PHASE 0
Function Description
LINE LOCK Option to synchronise several cameras with a system
V-PHASE Setting range 0
–255°
