30
5. Enter the ID of your camera.
6. As the port interface, select the appropriate COM interface.
7. Settings for the interface: Enter the baud rate used by your camera.
You do not need to change the other settings.
8. Click Save and Apply to apply the changes.
You can then control the high-speed motorised dome with the VMS software.
To access the configuration menu of your camera, select the preset 95. Alternatively, you can select
the Tour item on the LCD display and then select the configuration menu there.
You are in the configuration menu of the camera and can use the arrow keys to navigate the menu.
7. Key combinations
This high-speed motorised dome supports three control protocols: Pelco D, Pelco P and
Manchester.
These protocols are used by many recorders (such as HDVR 3.0/TVVR411x0) and controllers,
allowing them to control the high-speed motorised dome.
The factory setting of the camera is Pelco D/P (automatic detection) with 2400 bps (bits per
second) set. In the following, control using the control panel TVAC26000 will be explained.
Operation with other devices that use the Pelco D/P protocol is possible, but the keys can be
named differently.
Preset Function
33 Auto Flip 97 Start random scan
34 Pan Zero 98 Start image scan
35 Tour 1 99 Start pan scan
36 Tour 2 100 Start tilt scan
37 Tour 3 101 Start panorama scan
38 Tour 4 102 Tour 5
39 IR cut filter On 103 Tour 6
40 IR cut filter Off 104 Tour 7
41 Pattern 1 105 Tour 8
42 Pattern 2
43 Pattern 3
44 Pattern 4
92 Turn on the limit
settings
93 Set the limit settings
94 Reboot
95 OSD menu
96 Stop scan
