11.2 PIP

With this menu item you can adjust the settings of the picture in picture function.

Please note:

If you switch off the monitor the PIP settings will be lost.


PIP

Setup

VGA

Language

PIP Mode

< None >

PIP Source

< BNC2 >

PIP H Position

< 10 >

PIP V Position

< 10 >

PIP Swap

PIP Mode

Select the picture-in-picture size.

PIP Source

Select the input for the Picture-in-Picture function

PIP H Position

Adjusting the horizontal position of the picture-in-picture input.
Selection range 0 (left) till 10 (right)

PIP V Position

Adjusting the vertical position of the picture-in-picture source.
Selection range 0 (top) till 10 (bottom)

PIP Swap

With this function you can swap the main picture with the overlaid picture.
Choose the menu sub item and confirm this with the ► button.
