28
English
6. Mounting
6.1 Power supply
Before starting installation, ensure that the mains voltage and the rated voltage of the monitor
are identical.
6.2 Ventilation
Please ensure that there is adequate ventilation. In order to guarantee adequate ventilation, it is important
that the ventilation openings are not covered.
6.3 Wall Mount
For wall-mounting, please use a VESA compatible wall bracket. The mounting holes are arranged in a
square on the back of the monitor (centre-to-centre distance: 75 mm). They are compatible with the ABUS
TVAC10500 wall bracket.
Please observe the installation instructions accompanying the wall bracket.
The TFT monitor must be disconnected from the mains power during installation.
7. Connections
7.1. Connect the monitor to a PC or recorder via VGA.
Use a VGA cable for connecting the monitor to a PC or recorder.
