N e t w o r k Ap p l i a n c e F W S - 2 2 0 0
Stop bits indicate the end of a serial data packet. (A start bit indicates the
beginning).
The standard setting is 1 stop bit. Communication with slow devices may
require more than 1 stop bit.
None Default Flow Control
Hardware RTS/CTS
Flow control can prevent data loss from buffer overflow. When sending
data, if the receiving buffers are full, a ‘stop’ signal can be sent to stop the
data flow. Once the buffers are empty, a ‘start’ signal can be sent to
re-start the flow. Hardware flow control uses two wires to send start/stop
signals.
Disabled VT-UTF8 Combo Key
Support Enabled Default
Enable VT-UTF8 Combination Key Support for ANSI/VT100 terminals.
Disabled Default Recorder Mode
Enabled
On this mode enabled only text will be send. This is to capture Terminal
data.
Disabled Default Resolution 100x31
Enabled
Enables or disables extended terminal resolution.
80x24 Default Legacy OS Redirection
Resolution 80x25
On Legacy OS, the Number of Rows and Columns supported redirection.
Chapter 3 AMI BIOS Setup 3-23
