N e tw o r k A p p l i a n c e
F W S - 2 2 0 0
Chapter 2 Quick Installation Guide
2-9
2.11 Pin Header (USB2)
Pin Signal
Pin Signal
1 +5V
2 GND
3 USBD1-
4 GND
5 USBD1+
6 USBD2+
7 GND
8 USBD2-
9 GND
10
+5V
11 CD-L
2.12 RS-232 Box Header (COM2)
Pin Signal
Pin Signal
1 DCD
2 RXD
3 TXD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI
10
N.C
2.13 SATA Connector (SATA 1)
Pin Signal
Pin Signal
1 GND
2 TXP
3 TXN
4 GND
5 RXN
6 RXP
7 GND
