N e t w o r k Ap p l i a n c e F W S - 7 6 0 0
Chapter 2 Quick Installation Guide 2-13
23 +5V 24 GND
2.17 FAN Connector (FAN1, FAN2, FAN3)
Pin Signal Pin Signal
1 GND 2 +12V
3 SENCE
2.18 PS/2 Keyboard/ Mouse Connector (CN2)
CN2 Function
1 KB_DATA
2 KB_CLK
3 GND
4 +5V
5 MS_DATA
6 MS_CLK
7 NC
8 NC
2.19 SATA Power Connector (PWR1)
Pin Signal Pin Signal
1 +12V 2 GND
3 GND 4 +5V
2.20 LCM & Key Pad Control Connector (LCMA1)
Pin Signal Pin Signal
1 POWER 2 GND
