N e t w o r k Ap p l i a n c e F W S - 7 6 0 0
Chapter 1 General Information 1- 5
Expansion Interface Mini PCI Type III Socket & PCI/
PCI-X/ PCI-E［x1］slot
Note: FWS-7600 supports three types of add-on cards: PCI, PCI-X and
PCI-Express, and not intended to use for any TELECOMMUNICATION
NETWORK device. (Such as modem card.)
Watchdog Timer
RTC
Storage
1~255 steps, can be set with software
on Super I/O
Internal RTC
Internal：One 3.5" Hard Disk Drive Bay
System Fan Three 4cm Ball Bearing Fans
Color
LCM
Power Supply
Blue and Red
2 x16 characters with 4 keypad control
ATX 300W, auto range
Dimensions
Net Weight
EMC
Safety
I/O
Serial Port
Keyboard & Mouse
16.93” (W) x 19.69” (D) x 1.73”(H)
(430mm x 500mm x 44mm) —Chassis
9.84” (W) x 11.02” (D) (250mm x
280mm) —Board
17.6 lb (8 kg)
CE/FCC Class A
UL
Two COM ports: (Internal Pin Header
x 1)
COM 1: RS-232
COM 2: RS-232 (Pin Header)
Reserve pin header
