N e t w o r k Ap p l i a n c e F W S - 7 6 0 0
Chapter 1 General Information 1- 4
1.3 Specifications
System
Construction: 1U firewall heavy-duty steel system up
to 10 ports
CPU Intel
®
Xeon Quad Core 3200 series up
to 2.66GHz and Dual Core 3000 series
CPU up to 2.4GHz, Tc=82W @ 70℃
Memory 240-pin ECC DDRII 667 DIMM Socket
x 4, total up to 8GB, Support
Dual-Channel
LAN (Optional)
BIOS
IDE
SATA Interface
Solid Storage Disk
PCI-E［x1］10/100/1000Mb LAN
module x 4 w/ Intel 82573 (with 4-port
bypass), PCI-E［x4］Dual Fiber LAN
module x 2 w/Intel 82571, SFP x 4
Award Plug & Play FWH BIOS – 8Mb
ROM
ATA-100 x 1 channel (Supports
CD-ROM ATAPI devices)
SATA II x 2
Supports CFD Type II connector(ATA
mode)
Note: Please change the IDE BIOS setting to “Slave” when you use the
CF and IDE.
