Chapter 2 Hardware Installation

2-10

Step 5: Insert RJ-45 plug into the socket and mount to cable set’s
body. Make sure the latch of RJ-45 connector is in place





Step 6: Lock and tighten the nut of RJ-45 plug






Latch is in place
