R e m o t e T o u c h D i s p l a y
A G D - 3 1 7 R
Chapter 2 Hardware Installation
2-14
2.12 The Matching of the Remote Box and Remote Display
A1 Display (One to Multi/ Cascade) has to work with ACG-203-A1
A2 Display (One to one) has to work with ACG-203-A2
If you did not use AAEON’s Remote Displays, you have to use ACG-204
series to work with non-AAEON displays. The PC will connect to
ACG-203 series and the ACG-203 series will connect to ACG-204 series
through RJ-45 cables.
Note: ACG-203-A1 has to work with ACG-204-A1, and ACG-203-A2 has to
work with ACG-204-A2
