I n d u s t r i a l M o t h e r b o a r d E M B - C V 1 s e r i e s
Appendix B Mating Connector B - 4
BLUE
E-MOVE/EE0360
-1GGZ-00H
[GA].DIP
SATA_PWR1
Serial ATA
power
Connector
CATCH
(TF)WAFER.4P.1
80D.(M).2.5mm.
W/LOCK POWER
DIP.CATCH.1198-
700-04S.
SATA3G_1
SATA 0
Connector
LOTES
SATA CON 7P
S/T
G/F,DIP,CHARL
LOTES/ABA-SAT-
046-K13.DIP
SATA3G_2
SATA 1
Connector
LOTES
SATA CON 7P
S/T
G/F,DIP,CHARL
LOTES/ABA-SAT-
046-K13.DIP
USB56
USB 5 & 6
pin header
JVE
(TF)PIN
HEADER.5*2P.18
0D.(M).2.0mm.DI
P
WLAN
Mini PCI-E
SLOT
LOTES
MINI PCI-E
52P,0.8MM,9.0H
SMT
LOTES/AAA-PCI-
047-P01
[HF].SMD
Note: The Cable P/N with
“ * ” sign is for WiTAS series products.
