I n d u s t r i a l M o t h e r b o a r d E M B - C V 1 s e r i e s
Chapter 1 General Information 1-4
 Operating Temperature
32˚F~ 140˚F (0˚C ~ 60˚C)
 Storage Temperature -40
˚F~ 185˚F (-40˚C ~ 85˚C)
 Operating Humidity 5%~95% relative humidity,
non-condensing
Display
 Chipset Intel
®
Graphics Media Accelerator
3650
 Resolution Up to 1440x900 18/24-bit
 LCD Interface 18/24-bit LVDS
 Video Interface VGA x 1, DVI-D x 1
I/O
 Storage SATA x 2 (support AHCI mode)
(if use m-SATA, one SATA port
will be disable)
 Serial Port RS-232 x 4, RS-232/422/485 x 1
(RS-422/485 is selectable by
BIOS)
 Parallel Port STD/SPP/EPP
 USB USB2.0 x 6
(5x2 pin header for internal x 2,
onboard Type A connector x 4)
 Digital I/O Supports 8-bit (Programmable)
 PS/2 Port Keyboard/ Mouse x 1
 Audio Line-in, Mic-in, Line-out
