I n d u s t r i a l M o t h e r b o a r d E M B - C V 1 s e r i e s
Chapter 2 Quick Installation Guide 2 - 15
2.24 LVDS Panel Connector (LVDS)
Pin Signal Pin Signal
1 NC 2 NC
3 Panel power 4 GND
5 NC 6 NC
7 NC 8 NC
9 NC 10 NC
11 NC 12 NC
13 DDC_DATA 14 DDC_CLOCK
15 DATA3- 16 DATA3+
17 DATA2- 18 DATA2+
19 DATA1- 20 DATA1+
21 DATA0- 22 DATA0+
23 Panel power 24 GND
25 LVDS_CLOCK- 26 LVDS_CLOCK+
27 Panel power 28 GND
29 Backlight enable 30 Brightness control
NOTE: LVDS connector Vendor:
PINREX; Model: 712-76-30GWR8. Please refer the drawing
below, notice the location of PIN1, PIN2, PIN29 and PIN30.
