I n d u s t r i a l M o t h e r b o a r d E M B - C V 1 s e r i e s
Chapter 1 General Information 1-3
1.2 Specifications
System
 Processor Intel
®
Atom
™ D2550 Dual Core
Processor, up to 1.86GHz
 System Memory 204-pin single channel DDR3
800/1066 DIMM x 2, Max. 4GB
(When you install only one
memory module, install it on
DIMM A2 slot)
 Chipset Intel
®
NM10
 I/O Chipset ITE IT8783F
 Ethernet Realtek 8111E for
10/100/1000Base-TX, RJ-45 x 2
 BIOS AMI BIOS, 32MB ROM
 Wake On LAN Yes
 Watchdog Timer System reset: 1~255 steps
programmable
 H/W Status Monitoring Supports Power Supply Voltage,
Fan Speed, and Temperature
Monitoring
 Expansion Interface PCI-Express[x1] x 1,
Full-size Mini Card + SIM Card
slot x 1 (m-SATA option)
 Battery Lithium battery
 Power Requirement DC 12V
(selectable AT/ATX mode)
 Board Size
6.7”(L) x 6.7”(W)
(170 mm x 170 mm)
 Gross Weight 1.1 lb (0.5 Kg)
