AAEON EMB-9459T A2.0 - Manual (Page 61)

M i n i - I T X E M B - 9 4 5 9 T A 2 . 0
Appendix C Mating Connector C - 3
CN7
LVDS
Connector
E-Call
Board-Wire
Connector-30P
-Pitch=1.25m
m( E-call.0110-
01-553-300 or
compatible)
N/A
N/A
CN8
USB4 &
USB5
Connector
CATCH
2.00mm Pitch
10 pins
( CATCH
H754-2x5 or
compatible)
USB
Cable
1709100208
CN9
USB6
Connector
CATCH
2.00mm Pitch
10 pins
( CATCH
H754-2x5 or
compatible)
USB
Cable
1709100208
(But only one
USB
function)
CN10
LPT port
Connector
CATCH
2.00mm Pitch
26 pins
(CATCH.
A003-268 or
compatible)
LPT
cable
1701260200
CN11
PCI
Express
X4
Connector
FOXCONN
PCI-E X4
(FOXCONN.2
EG03217-D2D
-DF or
compatible)
N/A N/A
CN12
COM5
Connector
CATCH
2.00mm Pitch
10 pins
( CATCH
H754-2x5 or
compatible)
Serial
Port
Cable
1701100206
CN13
COM6
Connector
CATCH
2.00mm Pitch
10 pins
( CATCH
H754-2x5 or
compatible)
Serial
Port
Cable
1701100206
CN14
Digital I/O
Connector
CATCH
2.00mm Pitch
10 pins
( CATCH
H754-2x5 or
compatible)
N/A N/A
CN15
COM4
Connector
CATCH
2.00mm Pitch
10 pins Serial
Port
1701100206
