M i n i - I T X E M B - 9 4 5 9 T A 2 . 0
Appendix C Mating Connector C - 2
C.1 List of Mating Connectors and Cables
The table notes mating connectors and available cables.
Mating Connector Connector
Label
Function
Vendor Model No.
Availabl
e Cable
Cable P/N
CN1
DVI+VGA
Connector
Astron
45Pin-90D-
DIP (Astron
1860044-006-
R or
compatible)
N/A N/A
CN2
Audio
2Watt
Speaker
output
CATCH
WAFER
BOX-4Pin-
180D-Pitch
2.5mm(CATC
H.1191-700-04
S compatible)
N/A N/A
CN3
COM1and
COM2
Connector
Contek
D-SUB 9
Connector
Dual Port
(Contek.B-DG
N10910101 or
compatible)
N/A N/A
CN4
TV_out
Connector
CATCH
2.00mm Pitch
8 pins
( CATCH
H754-2x4 or
compatible)
TV-Out
Cable
1700080180
CN5
LCD
Inverter
Connector
CATCH
2.0mm pitch 5
pin (CATCH
HS-5P-2.0 or
compatible)
N/A
N/A
CN6
LVDS
Connector
E-Call
Board-Wire
Connector-30P
-Pitch=1.25m
m( E-call.0110-
01-553-300 or
compatible)
N/A
N/A
