2.37 UIM Card Slot (CN27)

Pin Signal

1 UIM_PWR

2 GND

3 UIM_RESET

4 UIM_VPP

7 UIM_CLK

6 UIM_DATA

2.38 HDD Power Connector (PWR1)

Pin Signal

1 +12V

2 GND

3 GND

4 +5V

Note: The max. rating of Pin1 is 12V @ 1A; the max. rating of Pin4 is 5V @

1A.

2.39 44Pin 2.0mm IDE Connector (IDE1)

Pin Signal

1 IDERST#

2 GND

3 D7

4 D8

5 D6

5 D9

7 D5

8 D10

9 D4

D11

11 D3

12 D12

13 D2

14 D13

15 D1

16 D14

17 D0

18 D15

19 GND

20 N.C

21 DREQ

22 GND

23 IOW#

24 GND

25 IOR#

26 GND
