M i n i - I T X E M B - 9 4 5 9 T A 2 . 0
Chapter 2 Quick Installation Guide 2 - 7
2.4 List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Label Function
JP1 1
st
LVDS Inverter Voltage for 18 Bits LCD Selection
JP2 COM2 Ring +5V/+12V Selection
JP3 1
st
LVDS Voltage for 18 Bits LCD Selection
JP4 Clear CMOS
JP5 2
nd
LVDS Voltage for 24 Bits LCD Selection
JP6 AT/ATX Power Mode Selection
JP7 2
nd
LVDS Inverter Voltage for 24 Bits LCD Selection
2.5 List of Connectors
The board has a number of connectors that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's connectors:
Label Function
CN1 VGA Display Connector
CN2 Audio 2Watt Speaker Output
CN3 COM1/COM2 Connector
CN4 TV Output Connector
CN5 1
st
LVDS Inverter Connector for 18 Bits LCD
CN6 2
nd
LVDS Connector for 24 Bits LCD
CN7 1
st
LVDS Connector for 18 Bits LCD
CN8 USB Port 4/5 Connector
CN9 USB Port 6 Connector
CN10 LPT Port Connector
