4 amd accelerated processing unit, 5 system memory, Amd accelerated processing unit -6 – AAEON EMB-KB1 User Manual
Page 14: System memory -6
EMB-KB1
2-6
2.4
AMD Accelerated Processing Unit
The motherboard comes with an AMD
®
1
st
Generation APU SoC Quad Core GX-
420CA, Dual-core GX-217GA (optional).
EMB-KB1 APU
APU
2.5
System memory
EMB-KB1 204-pin DDR3 / DD3L SO-DIMM sockets
DIMM_A1
DIMM_A2
This motherboard comes with two Double Data Rate 3 / Double Data Rate 3 Low
Voltage (DDR3/DD3L) Small Outline Dual Inline Memory Modules (SO-DIMM)
socket. The figure illustrates the location of the DDR3 / DDR3L DIMM socket:
NOTE: Use the SO-DIMM_A2 slot when inserting only one SO-DIMM.
