2-3 Chapter 2: Motherboard information
Connectors/Jumpers/Slots Page
1. LVDS connector (30-pin LVDS1) 2-19
2. COM1 Ring/+5V/+12V selection (6-pin J4) 2-10
3. ATX power connectors (24-pin EATXPWR1, 4-pin EATX_PWR2) 2-14
4. SO-DIMM memory slots 2-6
5. CPU and chassis fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN) 2-15
6. Minicard connector (MINI_CARD1, MINI_CARD2) 2-20
7. BIOS programmable connector (8-pin SPI1) 2-21
8. Standby Power LED (Main_PWR_LED1, SB_PWR_LED1) 2-11
9. Serial ATA 6.0Gb/s connectors (7-pin SATA6G_1, SATA6G_2) 2-18
10. SATA power connector (SATA_PWR1) 2-18
11. System panel connector (10-1 pin F_Panel) 2-17
12. Clear RTC RAM (CLRTC) 2-8
13. Serial port connectors (10-1 pin COM3~6) 2-21
14. USB 2.0 connector (10-1 pin USB67, USB45) 2-20
15. Digital I/O connector (DIO1) 2-22
16. LVDS panel voltage selection (3-pin J1) 2-9
17. Inverter voltage selection (3-pin J2) 2-9
18. Inverter backlight control of inverter selector (3-pin J3) 2-10
19. Speaker out connector (AMP_CON1) 2-21
20. Front panel audio connector (10-1 pin AAFP1) 2-16
21. Backlight inverter power connector (5-pin INV1) 2-19
