S u b C o m p a c t B o a r d G E N E - L N 0 5 R e v . B
Appendix C Mating Connector C - 2
C.1 List of Mating Connectors and Cables
The table notes mating connectors and available cables.
Mating Connector Connector
Label
Function
Vendor Model no.
Available
Cable
Cable P/N
CN2
CPU Fan
Connector
Catch
1190-700-03
S
N/A N/A
CN3
+5VSB Output
w/ SMBus
JST PHR-6 N/A
N/A
CN4
External
+5VSB Power
Input and
PS_ON#
JST XHP-3 ATX Cable 170220020B
CN5 SATA Port 2 Molex 0887505318
SATA
Cable
1709070500
CN6 SATA Port 1 Molex 0887505318
SATA
Cable
1709070500
CN7
LPC
Expansion I/F
JST
SHR-12V-S-
B
N/A N/A
CN8
External 5V
Input
Molex 19211-0003
Power
Cable
170204010P
CN9
External 12V
Input
Molex 19211-0003
Power
Cable
170204010R
CN10 Touch Screen JST SHR-9V-S-B N/A N/A
CN11
+5V Output for
SATA HDD
using
JST PHR-2
2 Pins For
SATA
Power
1702150155
CN13 COM Port #6 Molex 51021-0900
UART
Wafer
Cable
1701090150
CN14 USB Port #7 Molex 51021-0500
USB
Wafer
Cable
1700050207
CN15 COM Port #5 Molex 51021-0900
UART
Wafer
Cable
1701090150
