S u b C o m p a c t B o a r d G E N E - L N 0 5 R e v . B
Chapter 2 Quick Installation Guide 2-21
Address(Register)
BIOS Setting
(I2C address) Connector
Definition
Output Input
F75111 GPIO Setting
Port 1 @6Eh Pin 1 21h/Bit 0 22h/Bit 0 U69 Pin 6 (GPIO 20)
Port 2 @6Eh Pin 2 21h/Bit 1 22h/Bit 1 U69 Pin 7 (GPIO 21)
Port 3 @6Eh Pin 3 21h/Bit 2 22h/Bit 2 U69 Pin 8 (GPIO 22)
Port 4 @6Eh Pin 4 21h/Bit 3 22h/Bit 3 U69 Pin 24(GPIO 23)
Port 5 @6Eh Pin 5 21h/Bit 4 22h/Bit 4 U69 Pin 23(GPIO 24)
Port 6 @6Eh Pin 6 21h/Bit 5 22h/Bit 5 U69 Pin 22(GPIO 25)
Port 7 @6Eh Pin 7 21h/Bit 6 22h/Bit 6 U69 Pin 21(GPIO 26)
Port 8 @6Eh Pin 8 21h/Bit 7 22h/Bit 7 U69 Pin 20(GPIO 27)
2.40 Parallel Port (CN27)
Pin Signal P i n S i g n a l
1 STB 2 AFD#
3 D0 4 ERROR#
5 D1 6 PINIT#
7 D2 8 SLIN#
9 D3 10 Ground
11 D4 12 Ground
13 D5 14 Ground
15 D6 16 Ground
17 D7 18 Ground
19 ACK# 20 Ground
21 BUSY 22 Ground
23 PE 24 Ground
25 SLCT 26 N/C
