2.23 Touch Screen Connector (CN10)
P i n 8 - w i r e 5 - w i r e 4 - w i r e
1 Ground Ground Ground
2 Top Excite UL(Y) Top
3 Bottom Excite UR(H) Bottom
4 Left Excite LL(L) Left
5 Right Excite LR(X) Right
6 Top Sense SENSE N/C
7 Bottom Sense N/C N/C
8 Left Sense N/C N/C
9 Right Sense N/C N/C
2.24 +5V Output For SATA HDD (CN11)
Pin Signal
1 +5V (800mA)
2 Ground
2.25 Front Panel (CN12)
Pin Signal
(-) 1-2 (+) ATX Power-on Button
(-) 3-4 (+) HDD Active LED
(-) 5-6 (+) External Speaker
(-) 7-8 (+) Power LED
(-) 9-10 (+) System Reset Button
2.26 COM Port #6 (CN13)
Pin S i g n a l P i n S i g n a l
1 DCDF 2 DSRF
