OM-05136 T SERIES
MAINTENANCE & REPAIR PAGE E - 5
PARTS LIST
44163-286 and 44163-436 Repair Rotating Assemblies
1 IMPELLER 38615-093 11010 1
2 SEAL ASSEMBLY 46512-034 --- 1
3 IMPELLER ADJ SHIM SET 2X 17090 REF
4 SHAFT SLEEVE 31413-088 16000 1
5 SEAL PLATE 38272-119 10000 1
6 SEAL PLATE GASKET 38687-556 20000 1
7 INBOARD OIL SEAL 25258-344 --- 1
8 BEARING HOUSING 38251-208 10000 1
9 INBOARD BALL BEARING 23276-008 --- 1
10 VENTED PLUG 4823 15079 1
11 AIR VENT S1530 --- 1
12 REDUCING PIPE BUSH AP0402 15079 1
13 BEARING CAP GASKET 38683-268 18000 1
14 HEX HD CAPSCREW B0505 15991 4
15 LOCKWASHER J05 15991 4
16 IMPELLER SHAFT 38514-565 16040 1
17 SHAFT KEY N0408 15990 1
18 PIPE PLUG P06 15079 1
19 SEAL CVTY GAUGE 26714-011 --- 1
20 BRG CVTY GAUGE 26714-011 --- 1
21 SEAL CVTY DRAIN PLUG P04 15079 1
22 BRG HSG DRAIN PLUG P04 15079 1
23 PIPE PLUG P06 15079 1
24 BEARING CAP OIL SEAL 25258-344 --- 1
25 BRG RETAINING RING S248 --- 1
26 BEARING CAP 38322-221 10000 1
27 OUTBRD BALL BEARING 23422-408 --- 1
28 HEX HD CAPSCREW B0503-1/2 15991 4
29 LOCKWASHER J05 15991 4
30 IMPELLER WASHER 31167-025 15000 1
31 SOCKET HD CAPSCREW DM0503 15991 1
32 SEAL PLATE O‐RING 25152-259 --- 1
33 BRG HOUSING O‐RING 25152-363 --- 1
34 SHIPPING PLUG 11495 15079 2
35 SHIPPING PLUG 11495 15079 2
36 ROT ASSY SHIM SET 48261-058 --- 4
NOT SHOWN:
ROTATION DECAL 2613M --- 1
INSTRUCTION TAG 6588U --- 1
INDICATES PARTS RECOMMENDED FOR STOCK
FOR PUMPS WITH SERIAL NUMBERS BELOW 1244270, ORDER 38683-274/18000 BEARING CAP GASKET.
IF BOTH BEARING CAP AND GASKET MUST BE REPLACED, ORDER PARTS LISTED ABOVE.
