OM-06012
ULTRA V SERIES
MAINTENANCE & REPAIR
PAGE E - 7
PARTS LIST
46146-065 Ultra Mate Pump Assembly
If your pump serial number is followed by an “N”, your pump is NOT a standard production model. Contact
the Gorman‐Rupp Company to verify part numbers.
ITEM
NO.
PART NAME
PART
NUMBER
QTY
MATL
CODE
1
PUMP CASING
38219-306
10000
1
2
REPAIR ROTATING ASSY
VS3A60-B
44163-463
---
1
VS3A60-B /WW
44163-464
---
1
3
PIPE PLUG
P08
15079
4
4
PIPE PLUG
P12
15079
3
5
TRANSITION CHAMBER
38644-811
11010
1
6
PIPE PLUG
P04
15079
1
7
LOCK WASHER
J06
15991
15
8
HEX NUT
D06
15991
2
9
O‐RING
S1674
---
2
10
LOCK WASHER
J08
15991
8
11
HEX HD CAPSCREW
B0804
15991
4
12
HEX HD CAPSCREW
B0604-1/2
15991
2
13
HANDLE
12354
13010
1
14
BACK COVER NUT
31871-073
15000
4
15
LOCK COLLAR
38115-551
23030
4
16
ADJUSTING SCREW
31871-070
1500G
4
17
COVER PLATE ASSY
42111-831
---
1
-WARNING PLATE
2613EV
13990
1
-DRIVE SCREW
BM#04-03
17000
4
-PRESS RELIEF VALVE
26662-007
---
1
-WARNING DECAL
38816-302
---
1
18
O‐RING
25152-273
---
1
19
WEAR PLATE ASSY
46451-758
24150
1
20
STUD
C1213
15991
4
21
HEX HD CAPSCREW
B0606
15991
11
22
O‐RING
25152-277
---
1
23
O‐RING
25152-273
---
1
24
SPACER
33221-022
17040
4
25
HEX HD CAPSCREW
B0806
15991
4
OPTIONAL:
DISASSEMBLY TOOL
48711-020
---
1
G‐R HARD IRON PARTS:
-WEAR PLATE ASSY
46451-758
24160
1
SST PARTS:
-WEAR PLATE ASSY
46451-758
24170
1
HI TEMP SHUT-DOWN KITS:
-145
_F
48313-186
---
1
-130
_F
48313-256
---
1
-120
_F
48313-257
---
1
HIGH TEMP SHUT‐DOWN
THERMOSTAT KIT 145
_F
48313-172
---
1
AIR RELEASE VALVES:
-10# COMP SPRING
GRP33-07A
---
1
-25# COMP SPRING
GRP33-07
---
1
-80# COMP SPRING
GRP33-07B
---
1
INDICATES PARTS RECOMMENDED FOR STOCK
