OM-06012 ULTRA V SERIES
MAINTENANCE & REPAIR PAGE E - 3
PARTS LIST
Pump Model VS3A60-B (Including /WW)
(From S/N 1368380 Up)
If your pump serial number is followed by an “N”, your pump is NOT a standard production model. Contact
the Gorman‐Rupp Company to verify part numbers.
ITEM
NO.
PART NAME
PART
NUMBER
QTY
MATL
CODE
1 ULTRA MATE PUMP ASSY 46146-065 --- 1
2 HEX HD CAPSCREW B0807 15991 4
3 SUPPORT BRACE 41881-875 24150 1
4 DRIVE SCREW BM#04-03 17000 4
5 NAME PLATE 38818-149 13000 1
6 PUMP ASSEMBLY
VS3A60-B
46146-037 --- 1
VS3A60-B /WW 46146-038 --- 1
7 DISCHARGE GASKET 38687-060 --- 1
8 LOCK WASHER J10 15991 4
9 HEX HD CAPSCREW B1007 15991 4
NOT SHOWN:
LUBRICATION DECAL 38817-084 --- 2
G‐R DECAL GR-03 --- 1
“ULTRA V” DECAL 38816-342 --- 1
ROTATION DECAL 2613M --- 2
INSTRUCTION TAG 38817-023 --- 1
WARNING DECAL 2613FE --- 2
DISCHARGE STICKER 6588BJ --- 1
PRIMING STICKER 6588AH --- 1
SUCTION STICKER 6588AG --- 1
INSTRUCTION TAG 38817-011 --- 1
SMART SCROLL DECAL 38816-251 --- 1
OPTIONAL:
STAGED FLANGE KITS:
-4” X 3” NPT
48213-122 --- 1
-4” X 3” ASA SPOOL 48213-123 --- 1
-4” X 3” METRIC SPOOL 48213-124 --- 1
HI TEMP SHUT-DOWN KITS:
-145
_F 48313-186 --- 1
-130
_F
48313-256 --- 1
-120 _F 48313-257 --- 1
HIGH TEMP SHUT‐DOWN
THERMOSTAT KIT 145
_F
48313-172 --- 1
AIR RELEASE VALVES:
-10# COMP SPRING
GRP33-07A --- 1
-25# COMP SPRING GRP33-07 --- 1
-80# COMP SPRING GRP33-07B --- 1
INDICATES PARTS RECOMMENDED FOR STOCK
