STEP 2- MONITOR ADAPTER ATTACHMENT TO VESA PLATE
2
1
3
4
B
Connect VESA monitor plate with adapters to flat panel
STEP 2- MONITOR ADAPTER ATTACHMENT TO VESA PLATE
Connect VESA monitor plate with adapters to flat panel
14
Adapters to be used with panels that have the
following VESA mounting inserts (mm) (WxH);
300x200, 300x300, 300x400, 400x200, 400x300, &
400x400.
