Product component parts hardware part numbers – NXG Technology NX-MOUNT-ART-M User Manual
Page 3
A
P3
6
5
7
10
5mm
SPACER
X 8
2
1
3
M5 x 15
X 4
M6 x 15
X 4
M8 x 15
X 4
M5 x 25
X 4
M6 x 25
X 4
M8 x 25
X 4
4
9
SQUARE
WASHER
X 4
8
M4 x 15
X 4
M4 x 25
X 4
PRODUCT COMPONENT PARTS
HARDWARE PART NUMBERS
B
Product Components
Contents
Qty
Description
A
1 Wall Plate
B
1 VESA Monitor Plate
C
2 Monitor Adapters-1
D
2 Monitor Adapters-2
13
11
8 mm
LAG
BOLTS
X 2
ANCHOR
X 2
12
STEEL
WASHER
X 2
14
M6 x 12
ADAPTERS
SCREWS
X 8
C
D
