3 INTRODUCTION
The PASSIVE-1 expands on the core audio control capabilities of the venerable M-Patch 2, with
four selectable signal sources, USB I/O, talkback with built-in condenser microphone, ducking,
mute, mono summing and dual independent headphone amplifiers. Featuring entirely passive
operation from signal input to output, the PASSIVE-1 delivers the purest signal path possible,
giving you clean, transparent sound with no added audio artifacts or coloration.
PASSIVE-1 allows you to connect multiple input signals, route them to various destinations, and
control their levels via rotary volume attenuators. The PASSIVE-1 an ideal centerpiece for monitor
control in home, professional, and project studio applications. As it is a passive attenuator, we
recommend you set the volume knob in the maximum position, and attenuate the volume down to
the desired listening level.
3.1 Unboxing
Your SM Pro Audio PASSIVE-1 was carefully packed in the factory and the packaging was
designed to protect the unit from rough handling. Nevertheless, we recommend that you carefully
examine the packaging and its contents for any signs of physical damage, which may have
occurred in transit.
If the unit is damaged, please do not return it to us, but notify your dealer and the shipping
company immediately, otherwise claims for damage or replacement may not be granted. Shipping
claims must be made by the consignee.
