7 SPECIFICATIONS
Frequency Response:
Line Level Inputs and Outputs
+0.2 - -0.2dB 10hz to 30kHz
Noise:
Monitor A B, Studio Outputs
-120dBu Typical (passive signal)
2-Track -92dBu Typical
Outputs:
Line Level outputs
-10dBu/+30dBu (NOM/MAX)
Dynamic Range:
Line Inputs to outputs (monitor A B) 120dB minimum (passive signal)
Crosstalk:
Mute/Level OFF
120dB @1kHz (passive signal)
Volume Control range:
Dim Switch
-20dB
Master Volume studio attenuation
65dB max
USB:
Channels
2
Drivers Legacy type and ASIO
Compatibility All current USB Audio systems
